Deploy Secure Google Cloud VMs with Terraform and GitHub Actions in 2025

Automate VM provisioning, networking, and CI/CD pipelines using Infrastructure as Code best practices

Part 2 of my comprehensive Terraform on Google Cloud series – Building on your VPC foundation with compute resources and automation

Ready to automate your VM deployments like a DevOps pro? This tutorial builds directly on our Part 1 foundation, adding secure Compute Engine instances with automated GitHub Actions workflows. You’ll master firewall rules, Cloud NAT setup, and production-ready CI/CD patterns.

By the end of this guide, you’ll have a complete automated pipeline that deploys VMs to Google Cloud every time you push code to your GitHub repository.

Perfect for teams wanting to eliminate manual infrastructure deployments and embrace true DevOps automation.

What You’ll Learn in This Guide

  • Secure VM provisioning with proper service accounts and networking
  • Firewall rule management for SSH access and internet connectivity
  • Cloud NAT configuration for private VM internet access
  • GitHub Actions automation with service account authentication
  • Production CI/CD patterns for infrastructure deployment

Prerequisites

Before starting this tutorial, ensure you have:

✅ Completed Part 1 of this series (VPC and storage setup)
✅ GitHub account with repository access
✅ Git installed locally with basic knowledge
✅ GitHub personal access token created
✅ Same GCP project from Part 1 with billing enabled

Understanding Google Cloud Compute Components

What are Firewall Rules in GCP?

Firewall rules in Google Cloud are security policies that control inbound and outbound traffic to your VM instances and other resources within a VPC network. They work at the network level and are stateful – meaning return traffic is automatically allowed.

Key concepts:

  • Direction: INGRESS (incoming) or EGRESS (outgoing) traffic
  • Priority: Lower numbers = higher priority (0-65534)
  • Targets: Which resources the rule applies to (tags, service accounts)
  • Sources/Destinations: Where traffic can come from or go to
  • Protocols and Ports: What type of traffic is allowed

What is Cloud NAT?

Cloud NAT (Network Address Translation) provides outbound internet connectivity for VM instances that only have private IP addresses. This is essential for:

  • Security: VMs don’t need public IPs to access the internet
  • Cost optimization: Fewer external IP addresses needed
  • Compliance: Keeps resources private while allowing necessary internet access

What is Cloud Router?

Cloud Router is a networking service that provides dynamic routing capabilities. It’s required for Cloud NAT and enables:

  • Dynamic routing between VPCs and on-premises networks
  • BGP support for advanced networking scenarios
  • NAT gateway functionality when paired with Cloud NAT

Extending Your Terraform Configuration

Let’s add the new variables and resources to your existing Terraform setup from Part 1.

Add VM Variables (variables.tf)

Add these variables to your existing variables.tf file:

variable "zone" {
  type        = string
  description = "GCP zone for VM deployment"
  default     = "us-central1-b"
  validation {
    condition     = can(regex("^[a-z]+-[a-z]+[0-9]+-[a-z]$", var.zone))
    error_message = "Zone must be a valid GCP zone format (e.g., us-central1-b)."
  }
}

variable "vm_machine_type" {
  type        = string
  description = "Machine type for the VM instance"
  default     = "e2-standard-2"
  validation {
    condition = contains([
      "e2-micro", "e2-small", "e2-medium", "e2-standard-2",
      "e2-standard-4", "n1-standard-1", "n1-standard-2"
    ], var.vm_machine_type)
    error_message = "Machine type must be a valid GCP machine type."
  }
}

variable "prefix" {
  type        = string
  description = "Prefix for resource naming"
  default     = "main"
  validation {
    condition     = can(regex("^[a-z][a-z0-9-]{1,10}$", var.prefix))
    error_message = "Prefix must start with a letter, contain only lowercase letters, numbers, and hyphens, and be 2-11 characters long."
  }
}

variable "vm_disk_size" {
  type        = number
  description = "Boot disk size in GB"
  default     = 50
  validation {
    condition     = var.vm_disk_size >= 10 && var.vm_disk_size <= 2000
    error_message = "VM disk size must be between 10 and 2000 GB."
  }
}

variable "vm_image" {
  type        = string
  description = "VM boot disk image"
  default     = "debian-cloud/debian-12"
  validation {
    condition = contains([
      "debian-cloud/debian-12", "ubuntu-os-cloud/ubuntu-2204-lts",
      "centos-cloud/centos-7", "rhel-cloud/rhel-8"
    ], var.vm_image)
    error_message = "VM image must be a supported OS image."
  }
}

Update Variable Values (terraform.tfvars)

Add these values to your existing terraform.tfvars file:

# Existing variables from Part 1
project_id  = "your-gcp-project-id"
environment = "dev"
region      = "us-central1"
vpc_name    = "main-vpc"
subnet_name = "primary-subnet"
subnet_cidr = "10.0.1.0/24"

# New VM variables
zone            = "us-central1-b"
vm_machine_type = "e2-standard-2"
prefix          = "demo"
vm_disk_size    = 50
vm_image        = "debian-cloud/debian-12"

Create VM Resources (vm.tf)

Create a new file vm.tf for your compute resources:

# Service account for VM instances
resource "google_service_account" "vm_service_account" {
  project      = var.project_id
  account_id   = "${var.prefix}-vm-sa"
  display_name = "VM Service Account for ${var.environment}"
  description  = "Service account for VM instances with minimal required permissions"
}

# IAM roles for VM service account
resource "google_project_iam_member" "vm_sa_logging" {
  project = var.project_id
  role    = "roles/logging.logWriter"
  member  = "serviceAccount:${google_service_account.vm_service_account.email}"
}

resource "google_project_iam_member" "vm_sa_monitoring" {
  project = var.project_id
  role    = "roles/monitoring.metricWriter"
  member  = "serviceAccount:${google_service_account.vm_service_account.email}"
}

# Compute Engine VM instance
resource "google_compute_instance" "main_vm" {
  name                      = "${var.prefix}-${var.environment}-vm"
  project                   = var.project_id
  machine_type              = var.vm_machine_type
  zone                      = var.zone
  tags                      = ["ssh-allowed", "http-server"]
  allow_stopping_for_update = true

  # Enable deletion protection in production
  deletion_protection = var.environment == "prod" ? true : false

  # Boot disk configuration
  boot_disk {
    initialize_params {
      image = var.vm_image
      type  = "pd-standard"
      size  = var.vm_disk_size
      labels = {
        environment = var.environment
        managed-by  = "terraform"
      }
    }
    auto_delete = true
  }

  # Network configuration - private IP only
  network_interface {
    network    = google_compute_network.main_vpc.self_link
    subnetwork = google_compute_subnetwork.main_subnet.self_link

    # No external IP - will use Cloud NAT for internet access
    # Uncomment below for external IP:
    # access_config {
    #   nat_ip = google_compute_address.vm_external_ip.address
    # }
  }

  # Service account and scopes
  service_account {
    email  = google_service_account.vm_service_account.email
    scopes = [
      "https://www.googleapis.com/auth/cloud-platform",
      "https://www.googleapis.com/auth/logging.write",
      "https://www.googleapis.com/auth/monitoring.write"
    ]
  }

  # Metadata for VM configuration
  metadata = {
    enable-oslogin = "TRUE"
    startup-script = <<-EOF
      #!/bin/bash
      apt-get update
      apt-get install -y nginx
      systemctl start nginx
      systemctl enable nginx
      echo "<h1>Hello from ${var.prefix}-${var.environment}-vm</h1>" > /var/www/html/index.html
      echo "<p>Deployed with Terraform and GitHub Actions</p>" >> /var/www/html/index.html
    EOF
  }

  # Labels for resource management
  labels = {
    environment = var.environment
    managed-by  = "terraform"
    team        = "devops"
  }

  # Depends on the subnet being ready
  depends_on = [
    google_compute_subnetwork.main_subnet
  ]
}

# Optional: Static external IP (commented out for security)
# resource "google_compute_address" "vm_external_ip" {
#   name    = "${var.prefix}-${var.environment}-vm-ip"
#   project = var.project_id
#   region  = var.region
# }

Create Firewall Rules (firewall.tf)

Create a new file firewall.tf for network security:

# Ingress firewall rule for SSH access
resource "google_compute_firewall" "allow_ssh" {
  name    = "${var.environment}-allow-ssh"
  network = google_compute_network.main_vpc.name
  project = var.project_id

  description = "Allow SSH access to instances with ssh-allowed tag"
  direction   = "INGRESS"
  priority    = 1000

  allow {
    protocol = "tcp"
    ports    = ["22"]
  }

  # Restrict source ranges for better security
  # For production, use your specific IP ranges
  source_ranges = ["0.0.0.0/0"]  # Change this in production!
  target_tags   = ["ssh-allowed"]

  # Log firewall activity
  log_config {
    metadata = "INCLUDE_ALL_METADATA"
  }
}

# Ingress firewall rule for HTTP traffic
resource "google_compute_firewall" "allow_http" {
  name    = "${var.environment}-allow-http"
  network = google_compute_network.main_vpc.name
  project = var.project_id

  description = "Allow HTTP access to web servers"
  direction   = "INGRESS"
  priority    = 1000

  allow {
    protocol = "tcp"
    ports    = ["80", "8080"]
  }

  source_ranges = ["0.0.0.0/0"]
  target_tags   = ["http-server"]

  log_config {
    metadata = "INCLUDE_ALL_METADATA"
  }
}

# Egress firewall rule for internet access
resource "google_compute_firewall" "allow_egress" {
  name    = "${var.environment}-allow-egress"
  network = google_compute_network.main_vpc.name
  project = var.project_id

  description = "Allow outbound internet access"
  direction   = "EGRESS"
  priority    = 1000

  allow {
    protocol = "tcp"
    ports    = ["80", "443", "53"]
  }

  allow {
    protocol = "udp"
    ports    = ["53", "123"]
  }

  destination_ranges = ["0.0.0.0/0"]
  target_tags        = ["ssh-allowed", "http-server"]
}

# Internal communication firewall rule
resource "google_compute_firewall" "allow_internal" {
  name    = "${var.environment}-allow-internal"
  network = google_compute_network.main_vpc.name
  project = var.project_id

  description = "Allow internal communication within VPC"
  direction   = "INGRESS"
  priority    = 1000

  allow {
    protocol = "tcp"
    ports    = ["0-65535"]
  }

  allow {
    protocol = "udp"
    ports    = ["0-65535"]
  }

  allow {
    protocol = "icmp"
  }

  # Allow traffic from the VPC CIDR
  source_ranges = [var.subnet_cidr, "10.1.0.0/16", "10.2.0.0/16"]
}

Update Networking with Cloud NAT (networking.tf)

Add these resources to your existing networking.tf file:

# Cloud NAT for private VM internet access
resource "google_compute_router_nat" "main_nat" {
  name   = "${var.environment}-nat-gateway"
  router = google_compute_router.main_router.name
  region = var.region

  # NAT IP allocation
  nat_ip_allocate_option = "AUTO_ONLY"

  # Which subnets to provide NAT for
  source_subnetwork_ip_ranges_to_nat = "LIST_OF_SUBNETWORKS"

  subnetwork {
    name                    = google_compute_subnetwork.main_subnet.name
    source_ip_ranges_to_nat = ["ALL_IP_RANGES"]
  }

  # Logging for monitoring
  log_config {
    enable = true
    filter = "ERRORS_ONLY"
  }

  # Timeout settings
  min_ports_per_vm               = 64
  udp_idle_timeout_sec          = 30
  icmp_idle_timeout_sec         = 30
  tcp_established_idle_timeout_sec = 1200
  tcp_transitory_idle_timeout_sec  = 30
}

Update Outputs (outputs.tf)

Add these VM-related outputs to your existing outputs.tf:

# Existing outputs from Part 1...

# VM outputs
output "vm_name" {
  value       = google_compute_instance.main_vm.name
  description = "Name of the created VM instance"
}

output "vm_internal_ip" {
  value       = google_compute_instance.main_vm.network_interface[0].network_ip
  description = "Internal IP address of the VM"
}

output "vm_zone" {
  value       = google_compute_instance.main_vm.zone
  description = "Zone where the VM is deployed"
}

output "vm_service_account" {
  value       = google_service_account.vm_service_account.email
  description = "Service account email used by the VM"
}

output "ssh_command" {
  value       = "gcloud compute ssh ${google_compute_instance.main_vm.name} --zone=${var.zone} --project=${var.project_id}"
  description = "Command to SSH into the VM instance"
}

# NAT gateway output
output "nat_gateway_name" {
  value       = google_compute_router_nat.main_nat.name
  description = "Name of the Cloud NAT gateway"
}

Setting Up GitHub Actions Automation

Now let’s create an automated CI/CD pipeline that will deploy your infrastructure whenever you push code to GitHub.

Create GitHub Secrets

First, you need to store your service account credentials in GitHub secrets:

  1. Get your service account key content:
cat terraform-sa-key.json
  1. In your GitHub repository:
    • Go to Settings > Secrets and variables > Actions
    • Click New repository secret
    • Name: GCLOUD_SERVICE_ACCOUNT_KEY
    • Value: Paste the entire contents of your service account key file

Security Note: This approach using service account keys is for learning purposes. In Part 3, we’ll upgrade to Workload Identity Federation for keyless authentication, which is the production-recommended approach.

Create GitHub Actions Workflow

Create the workflow directory and file:

mkdir -p .github/workflows
touch .github/workflows/deploy.yml

Add this workflow configuration to deploy.yml:

name: Terraform Infrastructure Deployment

on:
  push:
    branches:
      - main
      - develop
  pull_request:
    branches:
      - main

env:
  PROJECT_ID: your-gcp-project-id  # Replace with your project ID
  TF_VERSION: 1.6.0

jobs:
  terraform:
    name: Terraform Plan and Apply
    runs-on: ubuntu-latest

    permissions:
      contents: read
      id-token: write
      pull-requests: write

    steps:
      - name: Checkout repository
        uses: actions/checkout@v4

      - name: Set up Google Cloud SDK
        uses: google-github-actions/setup-gcloud@v1
        with:
          version: 'latest'
          service_account_key: ${{ secrets.GCLOUD_SERVICE_ACCOUNT_KEY }}
          project_id: ${{ env.PROJECT_ID }}

      - name: Configure Terraform authentication
        run: |
          echo '${{ secrets.GCLOUD_SERVICE_ACCOUNT_KEY }}' > /tmp/gcp-key.json
          gcloud auth activate-service-account --key-file=/tmp/gcp-key.json
          gcloud config set project ${{ env.PROJECT_ID }}
          gcloud config set compute/region us-central1
          export GOOGLE_APPLICATION_CREDENTIALS=/tmp/gcp-key.json

      - name: Setup Terraform
        uses: hashicorp/setup-terraform@v3
        with:
          terraform_version: ${{ env.TF_VERSION }}

      - name: Terraform Format Check
        id: fmt
        run: terraform fmt -check -diff -recursive
        continue-on-error: true

      - name: Terraform Initialize
        id: init
        run: terraform init

      - name: Terraform Validation
        id: validate
        run: terraform validate

      - name: Terraform Plan
        id: plan
        run: |
          terraform plan -input=false -out=tfplan -detailed-exitcode
        continue-on-error: true

      - name: Comment PR with Plan
        if: github.event_name == 'pull_request'
        uses: actions/github-script@v7
        with:
          script: |
            const output = `#### Terraform Format and Style 🖌\`${{ steps.fmt.outcome }}\`
            #### Terraform Initialization ⚙️\`${{ steps.init.outcome }}\`
            #### Terraform Validation 🤖\`${{ steps.validate.outcome }}\`
            #### Terraform Plan 📖\`${{ steps.plan.outcome }}\`

            <details><summary>Show Plan</summary>

            \`\`\`terraform
            ${{ steps.plan.outputs.stdout }}
            \`\`\`

            </details>

            *Pusher: @${{ github.actor }}, Action: \`${{ github.event_name }}\`*`;

            github.rest.issues.createComment({
              issue_number: context.issue.number,
              owner: context.repo.owner,
              repo: context.repo.repo,
              body: output
            })

      - name: Terraform Apply
        if: github.ref == 'refs/heads/main' && github.event_name == 'push'
        run: terraform apply -input=false tfplan

      - name: Clean up credentials
        if: always()
        run: |
          rm -f /tmp/gcp-key.json
          rm -f tfplan

      - name: Output VM Information
        if: github.ref == 'refs/heads/main' && github.event_name == 'push'
        run: |
          echo "## 🚀 Deployment Complete!" >> $GITHUB_STEP_SUMMARY
          echo "| Resource | Value |" >> $GITHUB_STEP_SUMMARY
          echo "|----------|-------|" >> $GITHUB_STEP_SUMMARY
          echo "| VM Name | $(terraform output -raw vm_name) |" >> $GITHUB_STEP_SUMMARY
          echo "| Internal IP | $(terraform output -raw vm_internal_ip) |" >> $GITHUB_STEP_SUMMARY
          echo "| SSH Command | \`$(terraform output -raw ssh_command)\` |" >> $GITHUB_STEP_SUMMARY

Deploying Your Infrastructure

Local Deployment First

Before pushing to GitHub, test your configuration locally:

# Format and validate
terraform fmt -recursive
terraform validate

# Plan and apply
terraform plan -out=tfplan
terraform apply tfplan

# Verify deployment
terraform output

Expected Output

You should see output similar to:

vm_internal_ip = "10.0.1.2"
vm_name = "demo-dev-vm"
vm_zone = "us-central1-b"
ssh_command = "gcloud compute ssh demo-dev-vm --zone=us-central1-b --project=your-project-id"

Test VM Connectivity

# SSH into your VM (if you have gcloud configured)
gcloud compute ssh demo-dev-vm --zone=us-central1-b --project=your-project-id

# Test internet connectivity from VM
curl -I http://google.com

# Check nginx is running
curl localhost

Push to GitHub for Automated Deployment

Once local testing works:

git add .
git commit -m "Add VM deployment with GitHub Actions automation"
git push origin main

GitHub Actions will:

  1. Validate your Terraform code
  2. Plan the infrastructure changes
  3. Apply changes automatically on main branch
  4. Comment on pull requests with plan details

Monitoring Your Deployment

Check GitHub Actions

  1. Go to your repository on GitHub
  2. Click the Actions tab
  3. Watch your workflow run in real-time
  4. Check the job summary for deployment details

Verify in GCP Console

  1. Compute Engine > VM instances – see your VM
  2. VPC network > Firewall – check your firewall rules
  3. Network services > Cloud NAT – verify NAT configuration
  4. Logging > Logs Explorer – monitor VM and firewall logs

Test Your VM

# List your VMs
gcloud compute instances list

# SSH into the VM
gcloud compute ssh demo-dev-vm --zone=us-central1-b

# Inside the VM, test internet access
curl -I https://www.google.com

# Check nginx status
sudo systemctl status nginx
curl localhost

Production Considerations

Security Enhancements

Firewall Rules:

  • Restrict SSH access to specific IP ranges
  • Use IAP (Identity-Aware Proxy) for SSH access
  • Implement network tags consistently

Service Accounts:

  • Follow principle of least privilege
  • Use separate service accounts for different workloads
  • Regularly rotate service account keys

Monitoring and Logging

Enable Monitoring:

# Add to vm.tf
metadata = {
  enable-oslogin = "TRUE"
  google-monitoring-enabled = "TRUE"
  google-logging-enabled = "TRUE"
}

Set up Alerts:

  • VM instance health checks
  • High CPU or memory usage
  • Network connectivity issues
  • Unusual SSH access patterns

Cost Optimization

Right-sizing:

  • Monitor VM performance and adjust machine types
  • Use preemptible instances for non-critical workloads
  • Implement auto-shutdown for development VMs

Storage Optimization:

  • Use appropriate disk types (pd-standard vs pd-ssd)
  • Enable disk auto-deletion with VMs
  • Implement disk snapshots for backups

Troubleshooting Common Issues

Authentication Failures

# Re-authenticate gcloud
gcloud auth application-default login

# Verify project setting
gcloud config get-value project

# Check service account permissions
gcloud projects get-iam-policy YOUR_PROJECT_ID

VM Won’t Start

# Check VM status
gcloud compute instances describe VM_NAME --zone=ZONE

# View serial console output
gcloud compute instances get-serial-port-output VM_NAME --zone=ZONE

# Check quotas
gcloud compute project-info describe --project=PROJECT_ID

Network Connectivity Issues

# Test firewall rules
gcloud compute firewall-rules list

# Check routes
gcloud compute routes list

# Verify NAT configuration
gcloud compute routers get-nat-mappings ROUTER_NAME --region=REGION

What’s Next in Part 3

In our next tutorial, we’ll enhance this setup with:

🔜 Secure PostgreSQL deployment with Cloud SQL
🔜 Workload Identity Federation for keyless GitHub Actions
🔜 Private service connections for database security
🔜 Advanced networking with VPC peering

Key Takeaways

✅ Automated infrastructure reduces human error and increases deployment speed
✅ GitHub Actions integration enables true Infrastructure as Code workflows
✅ Proper firewall rules are essential for both security and functionality
✅ Cloud NAT provides secure internet access without public IPs
✅ Service account best practices improve security posture from the start

Ready to level up your infrastructure automation? This foundation of automated VM deployment sets you up perfectly for the advanced database and security patterns we’ll cover in Part 3!

Connect with me:

  • LinkedIn for more Google Cloud and DevOps content

Tags: #Terraform #GoogleCloud #GCP #GitHubActions #DevOps #InfrastructureAsCode #ComputeEngine #Automation

Akhilesh Mishra

Akhilesh Mishra

I am Akhilesh Mishra, a self-taught Devops engineer with 11+ years working on private and public cloud (GCP & AWS)technologies.

I also mentor DevOps aspirants in their journey to devops by providing guided learning and Mentorship.

Topmate: https://topmate.io/akhilesh_mishra/
